Get drivers and downloads for your Dell Dell Powered USB Hub. Download and install the latest drivers, firmware and software. Usb 2 0 hub driver free download - USB 2.0 Root Hub Device, VIA USB 2.0 Host Controller Driver, Generic Hub on USB 2.0 Bus, and many more programs var bingData = ; Navigation.

Jan 08,2020 • Filed to: USB Recovery • Proven solutions

Generic USB Hub driver issues are not very uncommon and of late users of Windows 7, 8, and 10 including Windows XP and Vista users have had cause to complain about generic hub driver issues. In this short article you will learn the process to fix this issue for free without the need to pay a dime to any system technician. We’ve got you covered.

Overview

When it comes to USB Hubs three different hub types come to mind. A root hub, a powered hub and a self powered hub. These hubs all have different capabilities but used for the same purpose which is to connect USB drives to a phone or computer. A Generic USB hub can be found in the Device Manager of your PC and what it does really is to split a single USB port into several ports as large as four to seven different ports. With a Generic USB hub you can connect your PC to several devices at once. While this feature saves you the stress of connecting and removing different drives, one major weakness it has is that devices connected through it cannot draw power of more than 100mAH. This can be a major problem that may lead to graver complications.

Part 1: Overview of Common Generic USB Hub Driver Issues

When it comes to USB Hubs, there are 3 common hub types.

A root hub
A powered hub
A self-powered hub.

All the above three hubs have different capabilities. But one thing is common about all of them - they all expand a single USB port into several so that you can connect more USB drives to a phone or computer.

A Generic USB hub gives you the leeway to connect to numerous computers simultaneously.

One notable aspect of this feature is that you can connect to different devices although, your devices will not be able to draw the power of over 100mAH. This is a major problem that may lead to graver complications.

Your USB hub might be working mighty fine, but after some time, it might start sending you 'device not recognized' errors for devices on some of its port.

These are some of the reasons that may lead to your USB hub being slow:

Devices connected to the same hubs undergo selective suspends. One of the devices receives a wake request. When an awake request happens before the suspend request has occurred, the devices on the hub get unstable.

And there are several ways to work around this problem.

If you are having driver issues associated with your Device’ Generic Hub below is a method to help you fix the problem.

Part 2: Update Generic USB Hub driver manually

Microsoft is known to provide drivers for most of the different types of USB drivers in use today. From Windows update you can download the Generic Hub driver. Here are the steps

Tap the Windows key + R to open Run box
Type the letters “devmgmt.msc” then tap OK

Double click the Universal Serial Bus Controllers category to expand it

Right click Generic USB Hub (or “Unknown device” depending on your PC) and click to update the driver

Choose the Automatic search option to driver software

Follow concluding instructions to complete the update

You may have to restart your PC for newly installed drivers to take effect depending on your PC.

If you follow these steps through and through all Generic USB Hub driver issues will be fixed immediately updated drivers are installed. If a manual update proves unsuccessful, try downloading an update driver program online and follow the instructions to update driver automatically.

Part 3: How to Recover Lost Data after Fixing Generic USB Hub driver issues in Windows

After repairing generic USB Hub Driver in Windows, it is more likely you'll lose data from the USB drives. If you've lost your data during the process, the best thing is to stay calm, because you can get all your data back.

And the best way to recover lost data is by getting the right data recovery tool that guarantees recovery of usable data.

Out there, there is a plethora of data recovery software. Some deliver results, some don't. But let's focus on only what's working.

Introducing Recoverit Data Recovery Software.

Download gfortran for mac. With over 5 million satisfied users worldwide, Recoverit data recovery tool has global trust to retrieve nearly all data loss scenarios.

Fast, Pain-free, and Readily Available Data Recovery: Restore lost data from fixing USB hub quickly and easily even when using the freemium version of Recoverit.
Thorough Scan for Comprehensive Data Recovery Solution: Recoverit scrapes deeper into your storage device, thoroughly knits pieces of your lost data to give you back usable files. The powerful Deep scan feature drills deeper into your media and recovers lost files even after tough data loss.
Recovery of Nearly all types of Data: It doesn't matter if you lost images, videos, emails, audios, document, pdf, or any kind of file, Recoverit will recover them all. The tool utilizes sophisticated scan technology to support an extensive list of files of over 1000 types of files, from all file systems.
Technical Support: Get 24/7/365 support whenever you hit a dead end when retrieving data with the Recoverit software.

Steps on How to Recover Lost Data After Fixing Generic USB Hubs in Windows

Step 1. Select device

Download and install Recoverit tool on your PC and select a USB from the USB hub you desire to recover.

Step 2. Scan the files

Hit the 'Scan' option after selecting a drive you wish to recover. This takes time depending on the file size and file type.

Step 3. Preview and Recover

After scanning, Recoverit will present all the recoverable files. Preview to select which file to recover and which not to recover.

Hit the recover button after selecting what you choose to keep.

Video Tutorial on How to Fix USB Device Not Recognized

USB Solution

Recover USB Drive
Format USB Drive
Fix/Repair USB Drive
Know USB Drive

-->

This topic provides an overview of the Universal Serial Bus (USB) driver stack architecture.

The following figure shows the architectural block diagram of the USB driver stack for Windows 8. The diagram shows separate USB driver stacks for USB 2.0 and USB 3.0. Windows loads the USB 3.0 driver stack when a device is attached to an xHCI controller. The USB 3.0 stack is new in Windows 8.

Windows loads the USB 2.0 driver stack for devices that are attached to eHCI, oHCI, or uHCI controllers. The USB 2.0 driver stack ships in Windows XP with Service Pack 1 (SP1) and later versions of the Windows operating system.

USB 3.0 driver stack

USB 3.0 driver stack

The USB 3.0 stack is new in Windows 8. Microsoft created the new drivers by using Kernel Mode Driver Framework (KMDF) interfaces. The KMDF driver model reduces complexity and improves stability.

USB 3.0 host controller driver (Usbxhci.sys)

The xHCI driver is the USB 3.0 host controller driver. The responsibilities of the xHCI driver include initializing MMIO registers and host memory-based data structures for xHCI controller hardware, mapping transfer requests from upper layer drivers to Transfer Request Blocks, and submitting the requests to the hardware. After completing a transfer, the driver handles transfer completion events from the hardware and propagates the events up the driver stack. It also controls the xHCI controller device slots and endpoint contexts.

The xHCI driver is new in Windows 8 and is not an extension of the eHCI miniport driver that was available in earlier versions of the operating system. The new driver was written by using Kernel Mode Driver Framework (KMDF) interfaces and uses KMDF for all controller power management and PnP events. Windows loads the xHCI driver as the function device object (FDO) in the device stack for the host controller.

USB host controller extension (Ucx01000.sys)

The USB host controller extension driver (an extension to KMDF) is the new extension to the underlying class-specific host controller driver, such as the xHCI driver. The new driver is extensible and is designed to support other types of host controller drivers that are expected to be developed in the future. The USB host controller extension serves as a common abstracted interface to the hub driver, provides a generic mechanism for queuing requests to the host controller driver, and overrides certain selected functions. All I/O requests initiated by upper drivers reach the host controller extension driver before the xHCI driver. Upon receiving an I/O request, the host controller extension validates the request and then forwards the request to the proper KMDF queue associated with the target endpoint. The xHCI driver, when ready for processing, retrieves the request from the queue. The responsibilities of the USB host controller extension driver are:

Provides USB-specific objects to the xHCI driver.
Provides KMDF event callback routines to the xHCI driver.
Manages and control the operations of the root hub associated with the host controller.
Implements features that are configurable by the client driver, like chained MDLs, streams, and so on.

USB hub driver (Usbhub3.sys)

The new hub driver, in the USB driver stack for 3.0 devices, uses the KMDF driver model. The hub driver primarily performs these tasks:

Manages USB hubs and their ports.
Enumerates devices and other hubs attached to their downstream ports.
Creates physical device objects (PDOs) for the enumerated devices and hubs.

Windows loads the hub driver as the FDO in the hub device stack. Device enumeration and hub management in the new driver are implemented through a set of state machines. The hub driver relies on KMDF for power management and PnP functions. In addition to hub management, the hub driver also performs preliminary checks and processing of certain requests sent by the USB client driver layer. For instance, the hub driver parses a select-configuration request to determine which endpoints will be configured by the request. After parsing the information, the hub driver submits the request to the USB host controller extension or further processing.

USB 2.0 driver stack

Windows loads the USB 2.0 driver stack for devices that are attached to eHCI, oHCI, or uHCI controllers. The drivers in the USB 2.0 driver stack ship in Windows XP with SP1 and later versions of the Windows operating system. The USB 2.0 driver stack is designed to facilitate high-speed USB devices as defined in the USB 2.0 specification.

At the bottom of the USB driver stack is the host controller driver. It consists of the port driver, Usbport.sys, and one or more of three miniport drivers that run concurrently. When the system detects host controller hardware, it loads one of these miniport drivers. The miniport driver, after it is loaded, loads the port driver, Usbport.sys. The port driver handles those aspects of the host controller driver's duties that are independent of the specific protocol.

The Usbuhci.sys (universal host controller interface) miniport driver replaces the Uhcd.sys miniclass driver that shipped with Windows 2000. The Usbohci.sys (open host controller interface) miniport driver replaces Openhci.sys. The Usbehci.sys miniport driver supports high-speed USB devices and was introduced in Windows XP with SP1 and later and Windows Server 2003 and later operating systems.

In all versions of Windows that support USB 2.0, the operating system is capable of managing USB 1.1 and USB 2.0 host controllers simultaneously. Whenever the operating system detects that both types of controller are present, it creates two separate device nodes, one for each host controller. Windows subsequently loads the Usbehci.sys miniport driver for the USB 2.0-compliant host controller hardware and either Usbohci.sys or Openhci.sys for the USB 1.1-compliant hardware, depending on the system configuration.

Above the port driver is the USB bus driver, Usbhub.sys, also known as the hub driver. This is the device driver for each hub on the system.

USB common class generic parent driver (Usbccgp.sys)

The USB common class generic parent driver is the Microsoft-provided parent driver for composite devices. The hub driver enumerates and loads the parent composite driver if deviceClass is 0 or 0xef and numInterfaces is greater than 1 in the device descriptor. The hub driver generates the compatible ID for the parent composite driver as 'USBCOMPOSITE'. Usbccgp.sys uses Windows Driver Model (WDM) routines.

The parent composite driver enumerates all functions in a composite device and creates a PDO for each one. This causes the appropriate class or client driver to be loaded for each function in the device. Each function driver (child PDO) sends requests to the parent driver, which submits them to the USB hub driver.

Usbccgp.sys is included with Windows XP with SP1 and later versions of the Windows operating system. In Windows 8, the driver has been updated to implement function suspend and remote wake-up features as defined in the USB 3.0 specification.

For more information, see USB Generic Parent Driver (Usbccgp.sys).

WinUSB (Winusb.sys)

Windows USB (WinUSB) is a Microsoft-provided generic driver for USB devices. WinUSB architecture consists of a kernel-mode driver (Winusb.sys) and a user-mode dynamic link library (Winusb.dll). For devices that don't require a custom function driver, Winusb.sys can be installed in the device's kernel-mode stack as the function driver. User-mode processes can then communicate with Winusb.sys by using a set of device I/O control requests or by calling WinUsb_Xxx functions. For more information, see WinUSB.

In Windows 8, the Microsoft-provided information (INF) file for WinUSB, Winusb.inf, contains USBMS_COMP_WINUSB as a device identifier string. This allows Winusb.sys to get automatically loaded as the function driver for those devices that have a matching WinUSB compatible ID in the MS OS descriptor. Such devices are called WinUSB devices. Hardware manufacturers are not required to distribute an INF file for their WinUSB device, making the driver installation process simpler for the end user. For more information, see WinUSB Device.

USB client driver

Each USB device, composite or non-composite, is managed by a client driver. A USB client driver is a class or device driver that is a client of the USB driver stack. Such drivers include class and device-specific drivers from Microsoft or a third-party vendor. To see a list of class drivers provided by Microsoft, see Drivers for the Supported USB Device Classes. A client driver creates requests to communicate with the device by calling public interfaces exposed by the USB driver stack.

A client driver for a composite device is no different from a client driver for a non-composite device, except for its location in the driver stack.

A client driver for a non-composite device is layered directly above the hub driver.

For a composite USB device that exposes multiple functions and does not have a parent class driver, Windows loads the USB generic parent driver (Usbccgp.sys) between the hub driver and the client driver layer. The parent driver creates a separate PDO for each function of a composite device. Client drivers (FDOs for functions) are loaded above the generic parent driver. Vendors might choose to provide a separate client driver for each function.

A USB client driver can run in either user mode or kernel mode, depending on the requirements of the driver. USB client drivers can be written by using KMDF, UMDF, or WDM routines.

Helper libraries for client drivers

Microsoft provides the following helper libraries to help kernel-mode drivers and applications to communicate with the USB driver stack:

Usbd.sys
Microsoft provides the Usbd.sys library that exports routines for USB client drivers. The helper routines simplify the operational tasks of a client driver. For instance, by using the helper routines, a USB client driver can build USB Request Blocks (URBs) for certain specific operations, such as selecting a configuration, and submit those URBs to the USB driver stack.
Usbdex.lib
This helper library is new for Windows 8. The library exports routines primarily for allocating and building URBs. Those routines replace some of the legacy routines exported by Usbd.sys. The new routines require the client driver to register with the USB driver stack, which maintains the handle for registration. That handle is used for calls to other Usbdex.lib routines. Certain URBs allocated by the new routines have an URB context that the USB driver uses for better tracking and processing. For more information, see Allocating and Building URBs.
Winusb.dll
Winusb.dll is a user-mode DLL that exposes WinUSB functions for communicating with Winusb.sys, which is loaded as a device's function driver in kernel mode. Applications use these functions to configure the device, retrieve information about the device, and perform I/O operations. For information about using these functions, see How to Access a USB Device by Using WinUSB Functions.
